Closed frame (design 020)
Frame with outside opening crossbars (design 030)
Frame with inside opening crossbars (design 040)
KR [mm] | H [mm] | Hz [mm] | LB [mm] | UB [mm] |
|---|---|---|---|---|
28 | 74 | 89 | 124 | 55 |
37 | 92 | 107 | 153 | 64 |
50 | 118 | 133 | 194 | 77 |
Load diagram for unsupported length depending on the additional load.
Sagging of the cable carrier is technically permitted for extended travel lengths, depending on the specific application.
Intrinsic cable carrier weight qk = 0.25 kg/m with Bi 10 mm. For other inner widths, the maximum additional load changes.
The gliding cable carrier must be guided in a channel. More information
Only designs 020 and 030 can be used for a gliding arrangement.
Reliable, robust with high availability. Your benefit from many years of experience combined with ongoing optimization, proven in tests and praxis. TRAXLINE® cables stand for competent system-supply with worldwide on-site service.
to TRAXLINE®From pre-assembled cables to complex, ready-to-connect systems, from lot size 1 to series – worldwide thousands of KABELSCHLEPP systems are reliably in use. The benefits of TOTALTRAX® systems are obvious: just one person of contact, one order number, delivery just-in-time to your production facility, shortest downtimes thanks to plug&play installation.
to TOTALTRAX®Reliable unrolling and optimum gliding for long travel lengths
to Support traysFor optimum placement with dynamic use of cables
to Strain relief devices
Configuration guidelines:
