The maximum cable diameter strongly depends on the bending radius and the desired cable type. Please contact us.
t
[mm]
|
hi
[mm]
|
hG
[mm]
|
Bk
[mm]
|
qk
[kg/m]
|
|---|---|---|---|---|
| 30.5 | 20.5 | 28.5 | Bi + 13 | 0.48 – 0.76 |
Bi
[mm]
| |||||
|---|---|---|---|---|---|
| 15 | 20 | 25 | 38 | 50 | 65 |
KR
[mm]
| |||||
|---|---|---|---|---|---|
| 55 | 75 | 95 | 125 | 145 | 180 |
TKA30
060
50
125
915
VS
The divider system is mounted on every 2nd chain link as a standard. As a standard, dividers or the complete divider system (dividers with height separations) are movable in the cross section (Version A).
The dividers are easily attached to the stay for applications with transverse accelerations and for applications laying on the side by simply turning them.
The locking cams click into place in the locking grids in the covers (Version B).
| Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
ax grid
[mm]
|
nT min |
|---|---|---|---|---|---|
| A | 3.5 | 7 | 5 | – | – |
| B | A | 8 | 6 | 2 | – |
| A | Bi [mm]
aT min [mm]
| 15 7.5 | 20 8 | 25 8.5 | 38 9 | 50 9 | 65 8.5 |
| Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
ax grid
[mm]
|
nT min |
|---|---|---|---|---|---|
| A | 3.5 | 7 | 5 | – | 2 |
| B | A | 8 | 6 | 2 | 2 |
| A | Bi [mm]
aT min [mm]
| 15 7.5 | 20 8 | 25 8.5 | 38 9 | 50 9 | 65 8.5 |
TS1
A
3
VD0
VD1
Please state the designation of the divider system (TS0, TS1 …), version and number of dividers per cross section [nT].
If using divider systems with height separation (TS1), please also state the positions [e.g. VD1] viewed from the left driver belt. You are welcome to add a sketch to your order.
The universal end connectors (UMB) are made from plastic and can be mounted from the top, from the bottom, or face on.
Recommended tightening torque: 3 Nm for cheese-head screws ISO 4762 - M4 x 12
The end connectors are also available as an option without cover sheets. Please state when ordering.
F – fixed point
M – driver
U – universal end connector
UMB
F
U
UMB
M
U
UMB
UMB
F
M
U
U
We recommend the use of strain reliefs at the driver and fixed point.
