The maximum cable diameter strongly depends on the bending radius and the desired cable type.
Please contact us.
t
[mm]
|
hi
[mm]
|
hG
[mm]
|
Bk
[mm]
|
qk
[kg/m]
|
---|---|---|---|---|
26 | 40 | 54 | Bi + 26 | 1.50 – 2.70 |
Bi
[mm]
| |||||||
---|---|---|---|---|---|---|---|
50 | 62 | 75 | 87 | 100 | 125 | 150 | 200 |
KR
[mm]
| |||
---|---|---|---|
75 | 100 | 125 | 150 |
TKR0260
100
030
125
800
VS
The divider system is mounted on every 2nd chain link as a standard. As a standard, dividers or the complete divider system (dividers with height separations) are movable in the cross section (Version A).
Fixable dividers are available for applications with lateral accelerations and for applications lying on the side.
The arresting cams click into place in the locking grids in the crossbars (version B).
Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
ax grid
[mm]
|
nT min |
---|---|---|---|---|---|
A | 3 | 8 | 5.6 | – | – |
B | A | 8 | 5.6 | 4 | – |
A | Bi [mm]
aT min [mm]
| 50 5 | 62 7 | 75 5.5 | 87 3.5 | 100 6 | 125 6.5 | 150 7 | 200 4 |
Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
ax grid
[mm]
|
nT min |
---|---|---|---|---|---|
A | 3 | 8 | 5.6 | – | 2 |
B | A | 8 | 5.6 | 4 | 2 |
A | Bi [mm]
aT min [mm]
| 50 5 | 62 7 | 75 5.5 | 87 3.5 | 100 6 | 125 6.5 | 150 7 | 200 4 |
Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
ax grid
[mm]
|
nT min |
---|---|---|---|---|---|
A | 3 | 26 | 20 | – | 2 |
B | A | 28 | 22 | 4 | 2 |
A | Bi [mm]
aT min [mm]
| 50 5 | 62 7 | 75 5.5 | 87 3.5 | 100 6 | 125 6.5 | 150 7 | 200 4 |
The dividers are fixed by the partitions, the complete divider system is movable in the cross section.
Aluminum section subdivisions are only available with ax > 26 mm.
TS0
A
3
VD0
VD1
Please state the designation of the divider system (TS0, TS1,...), version and number of dividers per cross section [nT ]. In addition, please also enter the chambers [K] from left to right, as well as the assembly distances [aT/ax] (as seen from the driver).
If using divider systems with height separation (TS1 – TS3), please also state the positions [e.g. VD23] viewed from the left driver belt. You are welcome to add a sketch to your order.
The universal mounting brackets (UMB) are made from plastic and can be mounted from the top, from the bottom or face on.
Recommended tightening torque:
0,6 Nm for screws M4
Bi [mm] | BEF [mm] | nz |
---|---|---|
50 | 76 | 2 x 3 |
62 | 88 | - |
75 | 101 | 2 x 5 |
87 | 113 | - |
100 | 126 | 2 x 7 |
125 | 151 | 2 x 9 |
150 | 176 | 2 x 11 |
200 | 226 | - |
F – fixed point
M – driver
U – universal mounting bracket
UMB
F
U
UMB
M
U
UMB
UMB
F
M
U
U
We recommend the use of strain reliefs at the driver and fixed point.
