Stay arrangement on every 2nd chain link, standard (HS: half-stayed)
Stay arrangement on each chain link (VS: fully-stayed)
The maximum cable diameter strongly depends on the bending radius and the desired cable type. Please contact us.
t
[mm]
|
hi
[mm]
|
hG
[mm]
|
hG'
[mm]
|
Bi
[mm]
|
BSt
[mm]
* |
Bk
[mm]
|
BEF
[mm]
|
qk
[kg/m]
|
---|---|---|---|---|---|---|---|---|
65 | 31 | 50 | 56 | 69 – 369 | 85 – 385 | BSt + 15 | BSt + 20 | 3.95 – 5.25 |
KR
[mm]
| |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
75 | 95 | 115 | 125 | 135 | 145 | 155 | 175 | 200 | 250 | 300 | 400 |
S0650
180
RS2
135
St
1430
HS
The divider system is mounted on each crossbar as a standard – on every 2nd chain link for stay mounting (HS – half-stayed).
As a standard, dividers or the complete divider system (dividers with height separations) are movable in the cross section (version A).
For applications with lateral acceleration and rotated by 90°, the dividers can be attached by simply clipping onto a socket (available as an accessory).
The socket additionally acts as a spacer between the dividers and is available in 1 mm increments between 3 – 50 mm (Version B).
Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
nT min |
---|---|---|---|---|
A | 11.5 | 13 | 10 | – |
The dividers can be moved in the cross section.
Vers. |
aT min
[mm]
|
ax min
[mm]
|
ac min
[mm]
|
nT min |
---|---|---|---|---|
A | 11.5 | 13 | 10 | 2 |
The dividers can be moved in the cross section.
TS1
A
3
VD0
VD1
Please state the designation of the divider system (TS0, TS1 …), version and number of dividers per cross section [nT].
If using divider systems with height separation (TS1), please also state the positions [e.g. VD1] viewed from the left driver belt. You are welcome to add a sketch to your order.
The end pieces are part of the divider system and don‘t have to be ordered separately.
End connectors made of steel. The connection variants on the fixed point and on the driver can be combined and changed later on, if necessary.
Caution: The standard connection variant FAI/MAI is only possible from Bk of 70 mm.
F – fixed point
M – driver
A – threaded joint to outside (standard)
I – threaded joint to inside
H – threaded joint, rotated 90° to the outside
K – threaded joint, rotated 90° to the inside
I – connection surface inside
A – connection surface outside
Steel
F
A
I
Steel
M
A
I
Steel
Steel
F
M
A
A
I
I
We recommend the use of strain reliefs at the driver and fixed point.
