Stay arrangement on every 2nd chain link, standard (HS: half-stayed)
Stay arrangement on each chain link (VS: fully-stayed)
The maximum cable diameter strongly depends on the bending radius and the desired cable type.
Please contact us.
qk 50 % **[kg/m]
|95||48||12||68||73||82 – 557||104 – 579||BSt + 21||BSt + 30||4||11||7.97 – 11.82|
Caution: The standard connection variant FAI/MAI is only possible from Bk of 122 mm.
F – fixed point
M – driver
A – threaded joint to outside (standard)
I – threaded joint to inside
H – threaded joint, rotated 90° to the outside
K – threaded joint, rotated 90° to the inside
I – connection surface inside
A – connection surface outside
We recommend the use of strain reliefs at the driver and fixed point.
