Load diagram for unsupported length depending on the additional load.
Sagging of the cable carrier is technically permitted for extended travel lengths, depending on the specific application.
Intrinsic cable carrier weight qk = 0.16 kg/m with Bi 15 mm. For other inner widths, the maximum additional load changes.
Only designs 020 and 030 can be used for a gliding arrangement.
